Product Description

The Series 1 Maritime Multi Display (MMD) uses fewer cable connections than the previous generation, which increases reliability whilst reducing component costs. All models can be delivered with either AC or DC input as standard and connections include DVI-I in, VGA out, VGA in, IEC inlet, IEC outlet and USB I/O.

The unit features LED Backlight Technology instead of traditional CCFL Backlighting which increases the light intensity life time. Further, with Optical Bonding Technology the viewing performance, reliability and lifespan increases dramatically. Bonding will also help with problems related to condensation, sunlight reflection, night vision and overheating. By factory standards the unit is ECDIS Compliant.

This product includes:
- 1 x DVI-D Cable (2m)
- 1 x VGA Cable (2m)
- 1 x Power Cable European Type F to IEC (1.8m)
- 1 x Power Cable US Type B to IEC (1.8m)
- 1 x Multifunction Cable (VSD100692-4) (30cm)
- 1 x DVI to RGB/VGA adapter

This Display can be used with:
Hatteland JH MMDBR STD-A1 Mounting Bracket
Hatteland JH MMDRO STD-A1 Rotary Bracket

General Specifications

Viewable Size 20.1"
Active Display Area 408mm (H) x 306mm (V)
Resolution 1600 x 1200
Aspect Ratio 4 : 3
Contrast Ratio 1000 : 1
Brightness 260cd / sqm
Response Time 30ms
Power Supply 115/230VAC - 50/60Hz or 24 VDC
Power Consumption 100W (MAX)
Signal Inputs • DVI IN: 1 x DVI-I 29P (female)
• VGA IN: 1 x HD D-SUB 15P (female)
• VGA OUT: 1 x HD D-SUB 15P (female)
• Multifunction: 1 x D-SUB 160P (female)
• USB: 1 x Type B (female)
• AC Power IN: 1 x Std. IEC inlet
• AC Power OUT: 1 x Std. IEC outlet (5A max)
• If DC Power IN: 1 x 2P D-SUB (male) Amphenol FCC17
IP Rating Protection: IP66 front - IP20 rear (EN60529)
Type Approval IEC 60945 4th (EN 60945:2002), IACS E10, IP66,
EU-RO-MR - Mutual Recognition

Size Specifications

Dimensions (mm) 534 (W) x 481 (H) x 87 (D)
Weight (kg) 13.5kg

Further information
Manufacturer Product Features and Details
Product Sheet
User Manual

Product Code

Warranty Terms
Warranty period: 1 year from date of purchase
Terms and conditions apply
